8051 Development Board
8051 Project Board v0.1
Download ManualINR: 250/- Buy Now!
8051 Project Board v0.1 is an ideal low cost development board for students, professionals, hobbyists and industry that can be used for developing projects based on 8051 microcontroller (μc). 8051 Project Board v0.1 employs NXP’s P89V51RD2 8051 μc along with the required dependencies – power supply and serial interface.
8051 Development Board
P89V51RD2 Development Board is a low cost development board which have all basic components needed for gaining a headstart on your first 8051 microcontroller projects. It is made from double sided PCB board to provide extra strength to the connector joints for increased reliability. Board can work on 12Vor DC supply. It has built-in reverse polarity protection. 7805 voltage regulator has heat sink for heat dissipation so that it can supply 1Amp current continuously without getting over heated. It has switches for reset and power. It also has RS232 interface with DB9 female connector based on MAX232. All the ports are connected to standard 10 pin FRC connectors. Open pads for connecting microcontroller’s pins to external devices are also provided. It can be programmed using Flash Magic programming utility of NXP’s own programming utility via serial port Buy Now!
